BLUE SEA 7049 200 AMP PANEL MOUNT 187 SERIES CIRCUIT BREAKER

Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker

7049 200 Amp Panel Mount 187 Series Circuit Breaker

Features:

Combines switching and circuit protection into a single device*
Clear, single lever operation
"Trip Free" design cannot be held "ON" during fault current condition
Waterproof
Recessed mounting holes for clean appearance
Large Clearance around terminal studs accecpt heavy gauge wire lugs
Robust 5/16 M8 terminals provide high torque connections
Large lever with vertical/horizontal orientation provides indication of trip status
Ignition protected - Safe for installation aboard gasoline powered boats

Specifications:

Interrupt Rating - 5,000 A@12V DC, 3,000A@24V DC, 1,500A@42V DC
Maximum Voltage Rating - 48 Volts DC
Operating Temperature Range - -40xC to 85xC
Circuit Breaker Type - Thermally responsive bi-metal blade
Circuit Breaker Class - Type III - switchable/manual reset - trip free
Terminal Stud Size - 5/16"-18
Terminal Stud Torque - 75 in-lb
Mounting Holes - Accept #10 (M5) Screw
Weight Lb (Kg) - 0.50 (0.23)
Case Material - Thermoset Polyester

Warning WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Click Here for Larger Image
Blue Sea Systems Part Number: 7049	Our SKU#: 40597
Our Price: $110.96 (MSRP: $164.99)
In Stock	Quantity:
Condition: BRAND NEW (NOT a "Refurb" or "Reman")
